Description
The ProMark 500 delivers RTK features in a light, cable-free rover that
provides maximum mobility and flexibility. The embedded Magellan BLADE
(Baseline Accurate Determination Engine) technology includes patented
GPS+GLONASS processing algorithms insuring maximum benefit from the
added GLONASS signals.
GNSS Characteristics
■ 75 channels:
– GPS L1 C/A L1/L2 P-code, L1/L2 full wavelength carrier
– GLONASS L1 C/A, L2-P code, L1/L2 full wavelength carrier
– SBAS: code & carrier (WAAS/EGNOS/MSAS)
– Low-signal acquisition and tracking engines for signal detection in difficult environments
■ Fully independent code and phase measurements
■ Magellan BLADE™ technology for optimal performance
■ Advanced multipath mitigation
Real-Time Accuracy (rms)
1-2 SBAS (WAAS/EGNOS/MSAS)
■ Horizontal: <3 m (10 ft)
Real-Time DGPS position
■< 0.8 m (2.62 ft)
Real-Time Kinematic Position (fine mode)
■ Horizontal 10 mm (0.033 ft ) + 1.0 ppm
■ Vertical 20 mm (0.065 ft) + 1.0 ppm Real-Time Performance Instant-RTK® Initialization
■ Typically 2-second initialization for baselines < 20 km
■ 99.9% reliability RTK Initialization range
■ > 40 km
Size
■ Unit: 22.8×18.8×8.4 cm (9×7.4×3.3 in)
Weight
■ GNSS receiver: 1.4 kg (3.1 lb)
Click here for Product Brochure (brochure shows options not included with this item)
